Nneɛma a wɔyɛ .

Phillips cheese ti a ɛyɛ mmerɛw .

Gyinapɛn: ASME B 18.6.4.
Thread Type: Ɔno ankasa-TWI NKWA .
Aguadide: Phillips cheese ti skru .
Wɔtoo din nso: Frearson ti nkɔnsɔnkɔnsɔn .
Nneɛma a wɔde yɛ: Carbon dade .
Agyapadeɛ Adesua: 4.8-12.9.
Diameter: 0#,1#,2#,3#,4#,5#,6#,7#,8#,10#,12,1/4,5/16
Awiei: Plain, tuntum, zinc a wɔde adura ho, ɔhyew a wɔde ahyɛ galvanized, oxidation, dacromet, phostrating, cadmium electroplate, nickel a wɔde adura ho
Ti no su: Fillister ti .
Drive Type: Cross Drive .
Ɔkwan/nsusuwii a ɛwɔ tip: Type AB .
MOQ: 1000kgs .
Bere a wɔde di kan: nnafua 30 kosi 60 .

Send Inquiry .

Nneɛma a wɔde yɛ adwuma .

Aya Fasteners (Hebei) Co., Ltd. yɛ wɔn a wɔn ho akokwaw sen biara a wɔyɛ Phillips Cheese Head Screw wɔ China no mu biako. Yɛsrɛ sɛ ntwentwɛn wo nan ase sɛ wobɛtɔ Phillips cheese head screw a ɛyɛ fɛ a wɔayɛ wɔ China wɔ ha fi yɛn adwumayɛbea hɔ. Sɛ wopɛ sɛ wo ne yɛn kɔ a, di yɛn ho nkɔmmɔ.

Phillips Cheese Head Screw-AYA

Sɛ́ wiase nyinaa adwumakuw a ɛde ano aduru a wɔde kyekyere nneɛma ho a wɔayɛ no sɛnea wɔpɛ no, Aya som adwuma no nso bɛn adetɔfo te sɛ Aya nneɛma. Efi hia a ɛsɛ sɛ wodi akyi-akɔ soro nnwuma ho asɛm mu no, Aya remmɔ mmɔden biara sɛ ɔbɛboa adetɔfo ma wɔadi ɔhaw biara a ɛsɔre a ɛsɔre no ho dwuma, na ama wɔayi adetɔfo ho dadwen afi hɔ.

Aguade ho nkyerɛkyerɛmu .

Aguade no din .	Phillips cheese ti a ɛyɛ mmerɛw .
Wɔato din nso .	Frearson ti a ɛyɛ den .
Atadeɛ	Carbon dade .
Susudua	ASME B 18.6.4.
Agyapadeɛ Adesua .	4.8-12.9
Ɔkwan/nsusuwii a ɛwɔ tip .	Type AB .
Diameter .	0#,1#,2#,3#,4#,5#,6#,7#,8#,10#,12#,1/4,5/16
Wie	oxide a ɛnyɛ den, tuntum, zinc a wɔde adura ho, ɔhyew a wɔde ahyɛ galvanized mu, oxidation, dacromet, phosphate, cadmium electroplate, nickel a wɔde adura ho .
Ti no su .	Filister ti .
Drive Type .	Cross Drive .
Thread type .	Self-Trapping screw asaawa .

Nsusuwii table .

Phillips Cheese Head Screw-2D

nominal diameter . d		0#	1#	2#	3#	4#	5#	6#	7#	8#	10#	12#	1/4	5/16
d	Nominal size .	0.06	0.073	0.086	0.099	0.112	0.125	0.138	0.151	0.164	0.19	0.216	0.25	0.3125
dk	Max .	0.096	0.118	0.14	0.161	0.183	0.205	0.226	0.248	0.27	0.313	0.357	0.414	0.518
dk	min .	0.083	0.104	0.124	0.145	0.166	0.187	0.208	0.229	0.25	0.292	0.334	0.389	0.49
h	Max .	0.043	0.053	0.062	0.07	0.079	0.088	0.096	0.105	0.113	0.13	0.148	0.17	0.211
h	min .	0.038	0.045	0.053	0.061	0.069	0.078	0.086	0.094	0.102	0.118	0.134	0.155	0.194
k	Max .	0.055	0.066	0.083	0.095	0.107	0.12	0.132	0.144	0.156	0.18	0.205	0.237	0.295
k	min .	0.047	0.058	0.066	0.077	0.088	0.1	0.111	0.122	0.133	0.156	0.178	0.207	0.262
M	Ref.	0.06	0.068	0.098	0.106	0.116	0.136	0.16	0.17	0.176	0.192	0.252	0.274	0.278
t	Ref.	0.03	0.035	0.05	0.055	0.069	0.054	0.078	0.088	0.095	0.112	0.128	0.148	0.19
N	Ref.	0.013	0.014	0.017	0.019	0.019	0.027	0.028	0.029	0.03	0.031	0.034	0.036	0.042
socket no.		0	0	1	1	1	2	2	2	2	2	3	3	3
Penetration no mu dɔ .	Max .	0.032	0.04	0.052	0.061	0.071	0.056	0.08	0.089	0.097	0.113	0.124	0.144	0.186
Penetration no mu dɔ .	min .	0.014	0.022	0.034	0.043	0.053	0.031	0.055	0.064	0.071	0.089	0.098	0.118	0.16

Aguade ho nsɛm .

Phillips Cheese Head Screw-detail

Mfaso a ɛwɔ nneɛma a wɔyɛ so .

Phillips Cheese Head Screw-advantages

Mfaso a ɛwɔ so sɛ .Phillips cheese ti a ɛyɛ mmerɛw .

1. Phillips cheese head screws yɛ screw types a ɛda nsow a ɛwɔ cylinder-atiri a ɛte sɛ nea ɛyɛ petee wɔ soro nanso ɛwɔ sorokɔ kakra a ɛfata slots a emu dɔ.

2. Ɔde Philips karka afiri a ɛtaa ba wɔ aguadi ne mfiridwuma tebea mu di dwuma, na ɛma ɛyɛ mmerɛw sɛ wobɛkɔ hɔ na ɛyɛ mmerɛw sɛ ɛbɛbɔ.

3. Ti no nsusuwii ne ne sorokɔ ma ɛfata ma counter bored taps.

4. Wɔde High-quality stainless steel a wɔde di dwuma ma asaawa mudi mu kura a ɛkɔ soro ne ne nyinaa a ɛyɛ den.

5. Wɔyɛ AYA screws wɔ mmeae a ɛyɛ adwuma yiye a ɛhwɛ ma ne nneɛma no yɛ papa.

6. AYA ne nnwumakuw a wɔde nneɛma kɔ amannɔne wɔ wiase nyinaa ayɛ biako de adi ahyɛde ahorow ho dwuma yiye.

Nhwehwɛmu a ɛyɛ papa .

Quality Check-AYA Fasteners

Packaging & Container a Wɔde Gu Mu .

Packing-AYA Fasteners

Nsɛm a wɔde di dwuma .

Usage-AYA Fasteners

Dɛn nti na ɛsɛ sɛ wopaw Aya?

AYA de nnwuma a ɛyɛ soronko ma 1000+ asɔremma a wofi wiase nyinaa afe biara, a ɛwɔ nkɔnsɔnkɔnsɔn som ano aduru nhyehyɛe soronko, nea ehia ara ne sɛ wobɛbɔ mouse no so na woanya ano aduru a wɔde kyekyere nneɛma a ɛyɛ soronko na woanya ɔpon-to{2}}pon so nnwuma no mu anigye.
