Nneɛma a wɔyɛ .

dade a ɛnyɛ den a wɔde yɛ asasetaw .

Gyinapɛn: DIN 125-2.
Aguadide: SS Flat Washer .
Nneɛma a wɔde yɛ: dade a ɛnyɛ den .
Grade:Grade A .
ntwemu: φ1.7,φ1.8,φ2.2,φ2.5,φ2.7,φ2.8,φ3.2,2,7,7,φ4.3,3,φ5.3,φ6.4,φ7.4,φ8,φ10.5,φφφφφφφφφφφbra
Φ25,Φ27,Φ28,Φ29,Φ31,Φ33,Φ34,Φ36,Φ37,Φ39,Φ40,Φ41,Φ43,Φ46,Φ50,Φ52,Φ54,Φ57,Φ58,Φ60,Φ62,Φ66,Φ70,Φ74,
Φ78,Φ82,Φ87,Φ93,Φ98,Φ104,Φ109,Φ114,Φ119,Φ124,Φ129,Φ134,Φ139,Φ144,Φ149,Φ155,Φ165
Finish: plain / bright / zinc a wɔde adura ho .
For Thread Size:M1.6,M1.7,M2,M2.3,M2.5,M2.6,M3,M3.5,M4,M5,M6,M7,M8,M10,M12,M14,M16,M18,M20,M22,M24,M26,M27,M28,M30,M32,
M33,M35,M36,M38,M39,M40,M42,M45,M48,M50,M52,M55,M56,M58,M60,M64,M68,M72,M76,M80,M85,M90,M95,M100,M105,M110,M115,M120,
M125,M130,M135,M140,M145,M150,M160
Agyapadeɛ a ɛwɔ hɔ: 300HV(HV300-400)
MOQ: 1000kgs .
Bere a wɔde di kan: nnafua 30 kosi 60 .

Send Inquiry .

Nneɛma a wɔde yɛ adwuma .

Aya Fasteners (Hebei) Co., Ltd. yɛ wɔn a wɔn ho akokwaw sen biara a wɔyɛ dade a ɛnyɛ den a wɔde hohoro nneɛma ho wɔ China no mu biako. Yɛsrɛ sɛ ntwentwɛn wo nan ase sɛ wobɛtɔ dadeɛ a ɛnyɛ den a ɛyɛ fɛ a wɔde yɛ asasetaw a wɔayɛ wɔ China wɔ ha afiri yɛn adwumayɛbea hɔ. Sɛ wopɛ sɛ wo ne yɛn kɔ a, di yɛn ho nkɔmmɔ.

product-1200-450

Sɛ́ wiase nyinaa adwumakuw a ɛde ano aduru a wɔde kyekyere nneɛma ho a wɔayɛ no sɛnea wɔpɛ no, Aya som adwuma no nso bɛn adetɔfo te sɛ Aya nneɛma. Efi hia a ɛsɛ sɛ wodi akyi-akɔ soro nnwuma ho asɛm mu no, Aya remmɔ mmɔden biara sɛ ɔbɛboa adetɔfo ma wɔadi ɔhaw biara a ɛsɔre a ɛsɔre no ho dwuma, na ama wɔayi adetɔfo ho dadwen afi hɔ.

Aguade ho nkyerɛkyerɛmu .

Aguade no din .	dade a ɛnyɛ den a wɔde yɛ asasetaw .
Atadeɛ	dade a ɛnyɛ den .
Aba	Grade A .
Susudua	DIN 125-2.
Diameter .	Φ1.7,Φ1.8,Φ2.2,Φ2.5,Φ2.7,Φ2.8,Φ3.2,Φ3.7,Φ4.3,Φ5.3,Φ6.4,Φ7.4,Φ8.4,Φ10.5,Φ13,Φ15,Φ17,Φ19,Φ21,Φ23,Φ25,Φ27,Φ28,Φ29,Φ31,Φ33,Φ34,Φ36,Φ37,Φ39,Φ40,Φ41,Φ43,Φ46,Φ50,Φ52,Φ54,Φ57,Φ58,Φ60,Φ62,Φ66,Φ70,Φ74,Φ78,Φ82,Φ87,Φ93,Φ98,Φ104,Φ109,Φ114,Φ119,Φ124,Φ129,Φ134,Φ139,Φ144,Φ149,Φ155,Φ165
Na asaawa kɛse .	M1.6,M1.7,M2,M2.3,M2.5,M2.6,M3,M3.5,M4,M5,M6,M7,M8,M10,M12,M14,M16,M18,M20,M22,M24,M26,M27,M28,M30,M32,M33,M35,M36,M38,M39,M40,M42,M45,M48,M50,M52,M55,M56,M58,M60,M64,M68,M72,M76,M80,M85,M90,M95,M100,M105,M110,M115,M120,M125,M130,M135,M140,M145,M150,M160
Agyapadeɛ Adesua .	300HV(HV300-400) .
Wie	Plain / hyerɛn / zinc a wɔde adura ho .

Nsusuwii table .

product-1200-481

Kɛseɛ

Φ1.7

Φ1.8

Φ2.2

Φ2.5

Φ2.7

Φ2.8

Φ3.2

Φ3.7

Φ4.3

Φ5.3

Φ6.4

Φ7.4

Φ8.4

Φ10.5

Φ13

Φ15

M	Na asaawa kɛse .
d	Min=Nkrabea kɛse .
d	Max .
d_c	Max=Nkrabea kɛse .
d_c	min .
h	Nominal size .
	Max .
	min .
d_a	Max .
d_a	min .
r	≈

M1.6	M1.7	M2	M2.3	M2.5	M2.6	M3	M3.5	M4	M5	M6	M7	M8	M10	M12	M14
1.7	1.8	2.2	2.5	2.7	2.8	3.2	3.7	4.3	5.3	6.4	7.4	8.4	10.5	13	15
1.84	1.94	2.34	2.64	2.84	2.94	3.38	3.88	4.48	5.48	6.62	7.62	8.62	10.77	13.27	15.27
4	4.5	5	6	6	7	7	8	9	10	12	14	16	20	24	28
3.70	4.20	4.70	5.70	5.70	6.64	6.64	7.64	8.64	9.64	11.57	13.57	15.57	19.48	23.48	27.48
0.3	0.3	0.3	0.5	0.5	0.5	0.5	0.5	0.8	1	1.6	1.6	1.6	2	2.5	2.5
0.35	0.35	0.35	0.55	0.55	0.55	0.55	0.55	0.9	1.1	1.8	1.8	1.8	2.2	2.7	2.7
0.25	0.25	0.25	0.45	0.45	0.45	0.45	0.45	0.7	0.9	1.4	1.4	1.4	1.8	2.3	2.3
2	2.1	2.6	2.9	3.1	3.2	3.6	4.1	4.7	5.7	6.8	7.8	9.2	11.2	13.7	15.7
1.8	1.9	2.4	2.7	2.9	3	3.4	3.9	4.5	5.5	6.6	7.6	9	11	13.5	15.5
0.15	0.15	0.15	0.2	0.2	0.2	0.2	0.2	0.2	0.2	0.2	0.2	0.4	0.4	0.4	0.4

Kɛseɛ

Φ17

Φ19

Φ21

Φ23

Φ25

Φ27

Φ28

Φ29

Φ31

Φ33

Φ34

Φ36

Φ37

Φ39

Φ40

Φ41

M	Na asaawa kɛse .
d	Min=Nkrabea kɛse .
d	Max .
d_c	Max=Nkrabea kɛse .
d_c	min .
h	Nominal size .
	Max .
	min .
d_a	Max .
d_a	min .
r	≈

M16	M18	M20	M22	M24	M26	M27	M28	M30	M32	M33	M35	M36	M38	M39	M40
17	19	21	23	25	27	28	29	31	33	34	36	37	39	40	41
17.27	19.33	21.33	23.33	25.33	27.33	28.33	29.33	31.39	33.62	34.62	36.62	37.62	39.62	40.62	41.62
30	34	37	39	44	50	50	50	56	60	60	66	66	72	72	72
29.48	33.38	36.38	38.38	43.38	49.38	49.38	49.38	55.26	58.80	58.80	64.80	64.80	70.80	70.80	70.80
3	3	3	3	4	4	4	4	4	5	5	5	5	6	6	6
3.3	3.3	3.3	3.3	4.3	4.3	4.3	4.3	4.3	5.6	5.6	5.6	5.6	6.6	6.6	6.6
2.7	2.7	2.7	2.7	3.7	3.7	3.7	3.7	3.7	4.4	4.4	4.4	4.4	5.4	5.4	5.4
17.7	20.2	22.4	24.4	26.4	28.4	30.4	31.4	33.4	35.4	36.4	38.4	39.4	41.4	42.4	43.6
17.5	20	22	24	26	28	30	31	33	35	36	38	39	41	42	43
0.4	0.6	0.7	0.7	0.7	0.7	1.2	1.2	1.2	1.2	1.2	1.2	1.2	1.2	1.2	1.3

Kɛseɛ

Φ43

Φ46

Φ50

Φ52

Φ54

Φ57

Φ58

Φ60

Φ62

Φ66

Φ70

Φ74

Φ78

Φ82

Φ87

Φ93

M	Na asaawa kɛse .
d	Min=Nkrabea kɛse .
d	Max .
d_c	Max=Nkrabea kɛse .
d_c	min .
h	Nominal size .
	Max .
	min .
d_a	Max .
d_a	min .
r	≈

M42	M45	M48	M50	M52	M55	M56	M58	M60	M64	M68	M72	M76	M80	M85	M90
43	46	50	52	54	57	58	60	62	66	70	74	78	82	87	93
43.62	46.62	50.62	52.74	54.74	57.74	58.74	60.74	62.74	66.74	70.74	74.74	78.74	82.87	87.87	93.87
78	85	92	92	98	105	105	110	110	115	120	125	135	140	145	160
76.80	83.60	90.60	90.60	96.60	103.60	103.60	108.60	108.60	113.60	118.60	123.40	133.40	138.40	143.40	158.40
7	7	8	8	8	9	9	9	9	9	10	10	10	12	12	12
8	8	9	9	9	10	10	10	10	10	11	11	11	13.2	13.2	13.2
6	6	7	7	7	8	8	8	8	8	9	9	9	10.8	10.8	10.8
45.6	48.6	52.6	54.6	56.6	60	63	65	67	71	75	79	83	87	92	97
45	48	52	54	56	59	62	64	66	70	74	78	82	86	91	96
1.3	1.3	1.3	1.3	1.3	1.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2
183	220	294	284	330	431	425	472	458	492	586	626	749	953	996	1250
1.3	1.3	1.3	1.3	1.3	1.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2

Kɛseɛ

Φ98

Φ104

Φ109

Φ114

Φ119

Φ124

Φ129

Φ134

Φ139

Φ144

Φ149

Φ155

Φ165

M	Na asaawa kɛse .
d	Min=Nkrabea kɛse .
d	Max .
d_c	Max=Nkrabea kɛse .
d_c	min .
h	Nominal size .
	Max .
	min .
d_a	Max .
d_a	min .
r	≈

M95	M100	M105	M110	M115	M120	M125	M130	M135	M140	M145	M150	M160
98	104	109	114	119	124	129	134	139	144	149	155	165
98.87	104.87	109.87	114.87	119.87	125	130	135	140	145	150	156	166
165	175	180	185	200	210	220	220	230	240	250	250	250
163.40	173.40	178.40	183.15	198.15*	208.15	218.15	218.15	228.15	238.15	248.15	248.15	248.15
12	14	14	14	14	16	16	16	16	18	18	18	18
13.2	15.2	15.2	15.2	15.2	17.2	17.2	17.2	17.2	19.2	19.2	19.2	19.2
10.8	12.8	12.8	12.8	12.8	14.8	14.8	14.8	14.8	16.8	16.8	16.8	16.8
102	108	113	118	123	128	133	138	143	148	153	159	169
101	107	112	117	122	127	132	137	142	147	152	158	168
2	2	2	2	2	2	2	2	2	2	2	2	2

1 wɔ nkyerɛwde a ɛwɔ gyinapɛn mu no mu no, φ119 ne DC bo a ɛba fam a ɛyɛ 188.15 hyia, nanso ɛsɛ sɛ nea ɛne no hyia a ɛtwetwe adwene wɔ ha no yɛ 1.85 mm, kyerɛ sɛ, bo a ɛba fam ankasa no yɛ 200-1.85=198.15 mm. (Wɔ DIN 522 mu no, bere a H nnu 4 na ade a wɔde yɛ no yɛ adesuakuw A no, D2 no nsusuwii a ɛma wotumi gyina ano no yɛ H15, na nea ɛne no hyia no yɛ 1.85 mm bere a DC yɛ mm 200).
2 ade a ɛwɔ mu:
1)Steel , Hardness Class 300HV, Hardness HV300-400 (adum na wɔahyɛ no den.
2)Stainless steel , hardness class 300hv, hardness HV300-400 (adum na ɛyɛ den;nneɛma (dade kuw) A2 , A4, F1, C1 anaa C4.
3)Washers betumi ayɛ non{1}}nsu a ɛyɛ mmerɛw anaa nneɛma foforo, a ɛhyɛ apam ase .
4)S a ɛnnkɔ soro nsen 0,5 mm no, ɛyɛ den no bɛyɛ HV 2 na H a ɛboro 0,5 mM, HV 10.

Aguade ho nsɛm .

product-1200-374

Mfaso a ɛwɔ nneɛma a wɔyɛ so .

product-1200-650

Mfaso a ɛwɔ dade a ɛnyɛ den a wɔde hohoro nneɛma so .

●Ade a ɛnyɛ dade a ɛnyɛ den a wɔde hohoro nneɛma te sɛ diski a ɛyɛ tratraa na ɛyɛ den yiye.

●Adwuma biara nni locking adwuma mu wɔ plain washer no mu, nanso wubetumi de adi dwuma na amma mating no ansɛe.

●Mfaso titiriw a ɛwɔ so sɛ wode dade a ɛnyɛ den a wɔde hohoro nneɛma ho no bedi dwuma ne sɛ ɛma wo nneɛma a ɛwɔ wo mu no ani yɛ yiye. Wubetumi nso de adi dwuma sɛ spacer a ɛda nneɛma a ɛwɔ soro no ntam.

●Wubehu bearing a ɛyɛ mmerɛw bere a wode dade a ɛnyɛ den a wɔde yɛ asasetaw a ɛwɔ ade a wɔde kyekyere nneɛma ho no di dwuma no.

●Wɔ Aya Fasteners no, yɛwɔ kuw bi a yɛbɛhwɛ sɛnea wɔhoro nneɛma a ɛnyɛ den no yiye ansa na yɛde akɔ baabi a worekɔ no.

●Sɛ wotɔ dade a ɛnyɛ den a wɔde hohoro nneɛma a ɛnyɛ den pii a, wubetumi ayɛ apam bi a ɛfata.
