Ɔkraman Point Hex Ti Screw .
Gyinapɛn: DIN 561 .
Thread Type: Asaawa a ɛyɛ mmerɛw/ asaawa a ɛyɛ fɛ .
Aguadide: Ɔkraman Point Hex Ti Screw .
Afei nso wɔtoo din: Hexagon ti set screws .
Nneɛma a wɔde yɛ: dade .
Agyapadeɛ Adesua: 14h, 22h
Ne kɛse: M20, M24, M30, M36, M42, M48, M56.
Awieɛ: Plain/ tuntum/ zinc a wɔde adura ho/ ɛyɛ den-Film passivated(ZSML)/ zinc flake, dwetɛ(ZFSHL)/ ɔhyew a wɔde ahyɛ galvanized/ organic/ geomet/ dacromet/ phostrating/ cadmium electroplate/ nickel plated
Ti no su: Hexagon ti .
Drive Type: Outer Hex .
Nsusuwii a ɛwɔ awiei: Ɔkraman a ɛyɛ pɛ .
MOQ: 1000kgs .
Bere a wɔde di kan: nnafua 30 kosi 60 .
Nneɛma a wɔde yɛ adwuma .
Aya Fasteners (Hebei) Co., Ltd. yɛ wɔn a wɔn ho akokwaw sen biara a wɔyɛ Dog Point Hex Ti Screw wɔ China no mu biako. Yɛsrɛ sɛ, ntwentwɛn wo nan ase sɛ wobɛtɔ Dog Point Hex Head Screw a ɛyɛ papa a wɔayɛ wɔ China wɔ ha no afi yɛn adwumayɛbea hɔ. Sɛ wopɛ sɛ wo ne yɛn kɔ a, di yɛn ho nkɔmmɔ.
Sɛ́ wiase nyinaa adwumakuw a ɛde ano aduru a wɔde kyekyere nneɛma ho a wɔayɛ no sɛnea wɔpɛ no, Aya a ɔyɛ obi a ɔpɛ nneɛma ho nhyehyɛe no nso bɛn adetɔfo te sɛ Aya nneɛma. Efi hia a ɛsɛ sɛ wodi akyi-akɔ soro nnwuma ho asɛm mu no, Aya remmɔ mmɔden biara sɛ ɔbɛboa adetɔfo ma wɔadi ɔhaw biara a ɛsɔre a ɛsɔre no ho dwuma, na ama wɔayi adetɔfo ho dadwen afi hɔ.
Aguade ho nkyerɛkyerɛmu .
Susudua | DIN 561 . |
Thread type . | Asaawa a ɛyɛ mmerɛw / asaawa a ɛyɛ fɛ . |
Adeɛ | Ɔkraman Point Hex Ti Screw . |
Wɔato din nso . | Hexagon ti set screws . |
Atadeɛ | Dadeɛ |
Agyapadeɛ Adesua . | 14H, 22H |
Diameter . | M20, M24, M30, M36, M42, M48, M56 |
Wie | Plain/ tuntum/ zinc a wɔde adura ho/ ɛyɛ den-Film passivated(ZSML)/ zinc flake, dwetɛ(zfshl)/ ɔhyew a wɔde ahyɛ galvanized/ organic/ geomet/ dacromet/ phostrating/ cadmium electroplate/ nickel plated |
Ti no su . | Hexagon ti . |
Drive Type . | Outer hex . |
Nsusuwii a ɛwɔ awiei . | Ɔkraman a ɔyɛ pɛ . |
MOQ . | 1000kgs . |
Bere a wɔde di kan . | Nnafua 30 kosi 60 . |
| Screw asaawa . d | M6 | M8 | M10 | M12 | M16 | M20 | M24 | M30 | M36 | M42 | M48 | M56 | |
| P | Prama（Asaawa a ɛyɛ mmerɛw .） | 1 | 1.25 | 1.5 | 1.75 | 2 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 | 5.5 |
| Prama（Asaawa a ɛyɛ fɛ .） | - | - | - | - | - | 2 | 2 | 2 | 3 | 3 | 3 | 3 | |
| a | Max . | 3 | 3.75 | 4.5 | 5.25 | 6 | 7.5 | 9 | 10.5 | 12 | 13.5 | 15 | 16.5 |
| da | Max . | 6.8 | 9.2 | 11.2 | 13.7 | 17.7 | 22.4 | 26.4 | 33.4 | 39.4 | 45.6 | 52.6 | 63 |
| dp | Max=Nkrabea kɛse . | 4 | 5.5 | 7 | 8.5 | 12 | 15 | 18 | 23 | 28 | 32 | 38 | 45 |
| min . | 3.82 | 5.32 | 6.78 | 8.28 | 11.73 | 14.73 | 17.73 | 22.67 | 27.67 | 31.61 | 37.61 | 44.61 | |
| e | min . | 8.79 | 11.05 | 14.38 | 17.77 | 19.92 | 26.75 | 33.53 | 39.98 | 51.28 | 61.31 | 72.61 | 83.91 |
| k | Nominal size . | 5 | 6 | 7 | 9 | 11 | 14 | 17 | 21 | 25 | 30 | 34 | 40 |
| min . | 4.85 | 5.85 | 6.82 | 8.82 | 10.79 | 13.79 | 16.79 | 20.74 | 24.74 | 29.74 | 33.69 | 39.69 | |
| Max . | 5.15 | 6.15 | 7.18 | 9.18 | 11.21 | 14.21 | 17.21 | 21.26 | 25.26 | 30.26 | 34.31 | 40.31 | |
| kw | min . | 3.4 | 4.1 | 4.8 | 6.2 | 7.6 | 9.7 | 11.8 | 14.5 | 17.3 | 20.8 | 23.6 | 27.8 |
| s | Max=Nkrabea kɛse . | 8 | 10 | 13 | 16 | 18 | 24 | 30 | 36 | 46 | 55 | 65 | 75 |
| min . | 7.78 | 9.78 | 12.73 | 15.73 | 17.73 | 23.67 | 29.67 | 35.38 | 45.38 | 54.26 | 64.26 | 74.26 | |
| z | Min=Nkrabea kɛse . | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 15 | 18 | 21 | 24 | 28 |
| Max . | 3.25 | 4.3 | 5.3 | 6.3 | 8.36 | 10.36 | 12.43 | 15.43 | 18.43 | 21.52 | 24.52 | 28.52 | |
| 1,Adeɛ a ɛwɔ mu: A)Steel, Agyapadeɛ Kuo(nneɛma): 14h, 22h gyinapɛn DIN ISO 898-5; b)Stainless dadeɛ, agyapadeɛ kuo(nneɛma): A2-50 Standard DIN ISO 3506; C)Nn{0}}Medadeɛ a ɛyɛ fɛ, agyapadeɛ kuo(nneɛma): CUZN=CU2 anaa Cu3 Standard DIN EN 28839, wɔ nea ɔyɛeɛ no paw mu | |||||||||||||
Aguade ho nsɛm .
Mfaso a ɛwɔ nneɛma a wɔyɛ so .
Mfaso a ɛwɔ kraman point hex ti screw so .
1. Dog Point Set Screws no wɔ beae a wɔatrɛw mu a ɛboro screw a wɔahyɛ da ayɛ no so asaawa a ɛne tokuru a ɛwɔ adwuma no mu no hyia, a ɛte sɛ dowel pin.
2. Eyi ma kwan ma shaft no dannan ne ho a ɛmma ɔfã no nkɔ.
3. Eyi ma saa screws yi yɛ adwuma yiye sen slotted screw products, sɛnea hex socket drive sɛ resistance kɛse ma Cam-out na wobetumi de adi dwuma ne power draiver, a ɛma wotumi de si hɔ ntɛmntɛm na torque a ɛkorɔn.
4. Wɔdannan set skru no socket drive no kosi sɛ ɛne ade a ɛwɔ mu no hyia, ansa na wɔde nhyɛso aba ade a ɛwɔ mu no so na wɔayɛ tumi a wɔde kyekyere nneɛma.
5. Wɔde Dog Point Hex Head Screw di dwuma ma ɔfã biako kɔ foforo koraa.
Nhwehwɛmu a ɛyɛ papa .
1. Yɛde yɛn adwene si su pa so na yɛwɔ QC kuw a wɔwɔ osuahu a yɛbɛhwɛ anammɔn biara a wɔyɛ so.
2. QC adwumayɛfoɔ a wɔn ho akokwa no bɛtumi ama adetɔfoɔ anya nhwehwɛmu a ɛyɛ pɛpɛɛpɛ a ɛfa nhwehwɛmu a ɛyɛ papa ho.
3. Yɛn digital nhyehyɛe no ma batch biara traceable fi raw materials to finished products. Wobetumi de nhwehwɛmu adansedi nkrataa a edi mũ ama bere a wɔabisa no.
Packaging & Container a Wɔde Gu Mu .
1. Nneɛma a wɔde kyekyere nneɛma ho a wɔde afiri yɛ no ma nneɛma a wɔde kyekyere nneɛma ho adwuma no yɛ papa na ɛyɛ ntɛmntɛm.
2. Wobetumi ayɛ nneɛma a wɔde ahyɛ mu no sɛnea adetɔfo ahiade te. na ɛbɛhyɛ mu den koraa na asiw nneɛma a wɔsɛe no a wɔnhwɛ kwan bere a wɔde rekɔ no ano.
3. Nneɛma a wɔde kyekyere nneɛma ho no ho hia ma nneɛma a wɔyɛ no yiye ne ahobammɔ nso. AYA ayɛ ano aduru foforo bere nyinaa a ɛbɛma nneɛma akɔ so ayɛ nea ɛfata wɔ bere a wɔde nneɛma rekɔ no mu.
Nsɛm a wɔde di dwuma .
Dɛn nti na ɛsɛ sɛ wopaw Aya?
AYA de nnwuma a ɛyɛ soronko ma 1000+ asɔremma a wofi wiase nyinaa afe biara, a ɛwɔ nkɔnsɔnkɔnsɔn som ano aduru nhyehyɛe soronko, nea ehia ara ne sɛ wobɛbɔ mouse no so na woanya ano aduru a wɔde kyekyere nneɛma a ɛyɛ soronko na woanya ɔpon-to{2}}pon so nnwuma no mu anigye.
