Flanged hexagon bolts .
Gyinapɛn: JIS B 1189 .
Thread Type: Nhama a ɛyɛ mmerɛw/ asaawa a ɛyɛ fã bi .
Aguadide: flanged hexagon bolts .
Wɔtoo din nso: Hex ti flange bolt .
Nneɛma a wɔde yɛ: Carbon dade .
Agyapadeɛ Adesua: 10.9.
Ntrɛwmu: M4/ m5/ m6/ m8/ m10/ m12.
Awiei: Plain, tuntum, zinc a wɔde adura ho, ɔhyew a wɔde ahyɛ galvanized, oxidation, dacromet, phostrating, cadmium electroplate, nickel a wɔde adura ho
Ti no su: Hexagon ti .
Drive Type: Abɔnten so hex .
MOQ: 1000kgs .
Bere a wɔde di kan: nnafua 30 kosi 60 .
Nneɛma a wɔde yɛ adwuma .
Aya Fasteners (Hebei) Co., Ltd. yɛ wɔn a wɔn ho akokwaw sen biara a wɔyɛ flanged hexagon bolts wɔ China no mu biako. Yɛsrɛ sɛ ntwentwɛn wo nan ase sɛ wobɛtɔ flanged hexagon bolts a ɛkorɔn a wɔayɛ wɔ China wɔ ha fi yɛn adwumayɛbea hɔ. Sɛ wopɛ sɛ wo ne yɛn kɔ a, di yɛn ho nkɔmmɔ.
Sɛ́ wiase nyinaa adwumakuw a ɛde ano aduru a wɔde kyekyere nneɛma ho a wɔayɛ no sɛnea wɔpɛ no, Aya som adwuma no nso bɛn adetɔfo te sɛ Aya nneɛma. Efi hia a ɛsɛ sɛ wodi akyi-akɔ soro nnwuma ho asɛm mu no, Aya remmɔ mmɔden biara sɛ ɔbɛboa adetɔfo ma wɔadi ɔhaw biara a ɛsɔre a ɛsɔre no ho dwuma, na ama wɔayi adetɔfo ho dadwen afi hɔ.
Aguade ho nkyerɛkyerɛmu .
Aguade no din . | Flanged hexagon bolts . |
Wɔato din nso . | Hex ti flange bolt . |
Atadeɛ | Carbon dade . |
Susudua | JIS B 1189 na ɛwɔ hɔ. |
Agyapadeɛ Adesua . | 10.9 |
Diameter . | M4/ M5/ M6/ M8/ M10/ M12 |
Wie | Plain, tuntum, zinc a wɔde adura ho, ɔhyew a wɔde ahyɛ galvanized, oxidation, dacromet, phosphate, cadmium electroplate, nickel a wɔde adura ho . |
Ti no su . | Hexagon ti . |
Drive Type . | Abɔnten so hex . |
Thread type . | Asaawa a ɛyɛ mmerɛw/ asaawa a ɛyɛ fã bi . |
Nsusuwii table .
| Screw asaawa . d | M4 | M5 | M6 | M8 | M10 | M12 | |
| P | Asaawa a ɛyɛ mmerɛw . | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.75 |
| Asaawa a ɛyɛ fɛ . | / | / | / | 1 | 1.25 | 1.25 | |
| ds | Max=Nkrabea kɛse . | 4 | 5 | 6 | 8 | 10 | 12 |
| min . | 3.9 | 4.9 | 5.9 | 7.85 | 9.85 | 11.8 | |
| s | Max=Nkrabea kɛse . | 7 | 8 | 10 | 12 | 14 | 17 |
| min . | 6.8 | 7.8 | 9.8 | 11.75 | 13.75 | 16.75 | |
| e | min . | 7.74 | 8.87 | 11.05 | 13.25 | 15.51 | 18.9 |
| dc | Max . | 10.5 | 12 | 14 | 17.5 | 21 | 25 |
| dw | min . | 7.5 | 9 | 11 | 14.5 | 18 | 22 |
| k | Max . | 3.6 | 4.5 | 5.4 | 6.9 | 8.5 | 10.2 |
| k1 | min . | 2.4 | 3 | 3.6 | 4.8 | 6 | 7.2 |
| c | Ref. | 0.8 | 1 | 1.2 | 1.4 | 1.6 | 2 |
| Max . | 0.95 | 1.15 | 1.4 | 1.6 | 1.85 | 2.25 | |
| min . | 0.65 | 0.85 | 1 | 1.2 | 1.35 | 1.75 | |
| r1 | Max . | 0.6 | 0.7 | 0.8 | 1.1 | 1.4 | 1.6 |
| r | min . | 0.2 | 0.2 | 0.25 | 0.4 | 0.4 | 0.6 |
| da | Max . | 4.7 | 5.7 | 6.8 | 9.2 | 11.2 | 14.2 |
| kw | min . | 1.6 | 2 | 2.3 | 3.1 | 3.9 | 4.7 |
| x | 1.4 | 1.6 | 2 | 2.5 | 3 | 3.5 | |
Aguade ho nsɛm .
Mfaso a ɛwɔ nneɛma a wɔyɛ so .
Mfaso a ɛwɔ so .
1. Flanged hexagon bolts betumi atew afã horow a ɛyɛ loose no so.
2. Carbon steel flange bolts tumi gyina tensile a ɛkorɔn, compression, torsion ne shear ahoɔden ano.
3. Hex head flange bolt no yɛ mmerɛw sɛ wobɛboaboa ano na woapaapae mu, na ɛnyɛ den sɛ wobɛhwɛ so.
4. Flange bolts rentumi mma phase nsakrae mma nneɛma a ɛwɔ nkitahodi no mu.
5. Flange fã a ɛwɔ hexagon flange bolt no mu no ma ɛyɛ beae kɛse a ɛne no di nkitaho.
6. AYA ankasa supply system, warehousing system, logistics ne transportation system betumi ama fasteners no de aba bere ano.
Nhwehwɛmu a ɛyɛ papa .
Nneɛma a etwa to a wɔhwɛ mu no yɛ asɛm titiriw. AYA wɔ sampling check system a edi mũ ma saa adwuma a ɛho hia yi na wɔbɛhwehwɛ nsɛm a ɛkɔ akyiri biara mu yiye.
Packaging & Container a Wɔde Gu Mu .
Aya adwini kuw no betumi adi adetɔfo ahiade soronko a ɛwɔ hɔ ma label ahorow no ho dwuma.
Nsɛm a wɔde di dwuma .
Dɛn nti na ɛsɛ sɛ wopaw Aya?
AYA de nnwuma a ɛyɛ soronko ma 1000+ asɔremma a wofi wiase nyinaa afe biara, a ɛwɔ nkɔnsɔnkɔnsɔn som ano aduru nhyehyɛe soronko, nea ehia ara ne sɛ wobɛbɔ mouse no so na woanya ano aduru a wɔde kyekyere nneɛma a ɛyɛ soronko na woanya ɔpon-to{2}}pon so nnwuma no mu anigye.
Tags a ɛyɛ hyew .: Flanged Hexagon Bolts, China, Wɔn a Wɔde Nneɛma Ma, Wɔn a Wɔyɛ, Adwumayɛbea, Kɔtɔ, Bo, Wɔtɔn, Wɔyɛ wɔ China
